Product Details:
|
| Application: | Garden | Color Temperature(CCT): | 2800K-6500K |
|---|---|---|---|
| IP Rating: | IP66 | Lamp Body Material: | Aluminum |
| Beam Angle(°): | 25°/60°/90°/120° | CRI (Ra>): | 80 |
| Input Voltage(V): | AC 85-265V | Lamp Luminous Efficiency(lm/w): | 160-190, 160-190lm/W |
| Lamp Luminous Flux(lm): | 48000 | Warranty(Year): | 5-Year |
| Working Lifetime(Hour): | 50000 | Working Temperature(℃): | -40 - 60 |
| Color Rendering Index(Ra): | 70 | Light Source: | LED |
| Support Dimmer: | Yes | Lighting Solutions Service: | Lighting And Circuitry Design, Onsite Metering, DIALux Evo Layout, LitePro DLX Layout, Auto CAD Layout, Agi32 Layout |
| Lifespan (hours): | 50000 | Working Time (hours): | 50000 |
| Product Weight（kg）: | 9.9 | Product Name: | Led Floodlight |
| Keyword: | LED Floodlight Waterproof IP66 Outdoor | Power: | 300W |
| Beam Angle: | 25°/60°/90°/120° | IP Grade: | IP66 Wateproof |
| LED Driver: | Ushineray | LED Chip: | Lumileds 2835 |
| Usage: | Outdoor Garden Landscaping Decorative | Material: | Aluminum+glass |
|
Model
|
YXR-FL-30W-S
|
YXR-FL-60W-S
|
YXR-FL-100W-S
|
YXR-FL-200W-S
|
YXR-FL-300W-S
|
YXR-FL-400W-S
|
YXR-FL-500W-S
|
||||||
|
Power(W)
|
30
|
60
|
100
|
200
|
300
|
400
|
500
|
||||||
|
Driver
|
Ushineray
|
Ushineray
|
Ushineray
|
Moso
|
Moso
|
Moso
|
Moso
|
||||||
|
Size(mm)
|
168*120*36.3
|
230*180*69.5
|
280*215*69.8
|
459.4*322.5*71.3
|
459.4*322.5*71.3
|
585*420*71.8
|
585*420*71.8
|
||||||
|
N.W(kg)
|
0.95
|
2.6
|
3.45
|
6.6
|
6.9
|
10.8
|
11
|
||||||
|
Input Voltage
|
AC85-265V; AC100-277V;
|
|
|
|
|
|
|
||||||
|
Efficiency
|
160-190 lm/w
|
|
|
|
|
|
|
||||||
|
Beam Angle
|
25°/ 60°/ 90°/ 120°
|
|
|
|
|
|
|
||||||
|
LED Chip
|
Lumilleds 2835
|
|
|
|
|
|
|
||||||
|
CCT
|
2800 - 6500K
|
|
|
|
|
|
|
||||||
|
CRI
|
≥70Ra
|
|
|
|
|
|
|
||||||
|
PF
|
＞0.97
|
|
|
|
|
|
|
||||||
|
THD
|
15%＜THD＜20%
|
|
|
|
|
|
|
||||||
|
Work Temp
|
-40~60℃
|
|
|
|
|
|
|
||||||
|
Humidity
|
25%~90% RH, no condensing
|
|
|
|
|
|
|
||||||
|
IP Grade
|
IP66
|
|
|
|
|
|
|
||||||
|
IK Grade
|
IK08
|
|
|
|
|
|
|
||||||
|
Life Span
|
≥50000h
|
|
|
|
|
|
|
||||||
|
Product Material
|
Aluminum alloy+PC lens
|
|
|
|
|
|
|
||||||
|
Power Wire
|
Rubber cable(3*1mm²) L=0.5m
|
|
|
|
|
|
|
||||||
