Product Details:
|
| Warranty(Year): | 5-Year | Color Rendering Index(Ra): | 80 |
|---|---|---|---|
| Support Dimmer: | Yes | Lighting Solutions Service: | Lighting And Circuitry Design, DIALux Evo Layout, LitePro DLX Layout, Agi32 Layout, Auto CAD Layout, Onsite Metering, Project Installation |
| Lifespan (hours): | ≥50000 | Working Time (hours): | 50000 |
| Product Weight（kg）: | 3.6 | Light Source: | LED, LED |
| Input Voltage(V): | AC 85-265V | Lamp Luminous Flux(lm): | 3880 |
| Lamp Luminous Efficiency(lm/w): | 140 | CRI (Ra>): | 80 |
| Color Temperature(CCT): | Warm White 2900-3100K, Neutral White 4800-5200K | Working Temperature(℃): | -20 - 40 |
| Working Lifetime(Hour): | 50000 | IP Rating: | IP66 |
| Emitting Color: | Warm White/ Neutral White | Lamp Body Material: | Aluminum Alloy |
| Item Type: | Advertising Lights | Product Name: | LED Billboard Light |
| Keyword: | Outdoor LED Light Advertising | Application: | Advertising LED Light |
| Voltage: | 36W | Efficcacy: | 110 Lm/W ±5% |
| Power Supplier: | UShineray | LED Light Source: | Sanan 2835 |
| Waterproof: | IP66 | Material: | ADC12 Aluminum Housing |
| Highlight: | 36w led advertising billboard,360 led advertising billboard,36w outdoor led billboard |
||
|
Model No.
|
YXR-AFL-36W-W
|
YXR-AFL-36W-B
|
|
|
Power
|
36W
|
36W
|
|
|
Body Color
|
White
|
Black
|
|
|
Lumen
|
5050 lm
|
|
|
|
Net Weight
|
3.4kg
|
|
|
|
Product Size
|
L825*W173*H110 mm
|
|
|
|
LED Chip
|
San'an 2835
|
|
|
|
Input Voltage
|
AC85-265V
|
|
|
|
Lumens
|
3880lm
|
|
|
|
CCT
|
Warm white 2900-3100K, neutral white 4800-5200K
|
|
|
|
PF
|
>0.95
|
|
|
|
CRI
|
≧80Ra
|
|
|
|
THD
|
15%＜THD＜20%
|
|
|
|
Beam Angle
|
120°
|
|
|
|
Work Temp
|
-20~40℃
|
|
|
|
Humidity
|
25%~90% no condensing
|
|
|
|
Life Span
|
≧50000H
|
|
|
|
IP Grade
|
IP66
|
|
|
|
IK Grade
|
IK08
|
|
|
|
Product Material
|
ADC12 Aluminum housing
|
|
|
|
Electronic Safety Grade
|
Class I
|
|
|
|
Power Wire
|
Rubber cable(3*1mm²) L=0.5M
|
|
|
