Product Details:
|
| Application: | Outdoor Sports Venues;parking Lots;football Fields;fields | Warranty(Year): | 5-Year |
|---|---|---|---|
| Color Rendering Index(Ra): | 80 | Light Source: | LED |
| Support Dimmer: | Yes | Lighting Solutions Service: | Lighting And Circuitry Design, DIALux Evo Layout, LitePro DLX Layout, Auto CAD Layout, Agi32 Layout |
| Working Time (hours): | 50000 | Keyword: | LED Floodlight Waterproof IP66 Outdoor |
| Highlight: | 500w stadium spotlight,stadium spotlight ra80,500w led arena lights |
||
The 500W stadium LED light provides high impact resistance, making it perfect for arenas where durability is crucial. Its robust design ensures it withstands physical impacts and rough handling, offering consistent and powerful lighting for any high-energy sporting event.
Product Features
| Model | YXR-QC-500W-B |
| Power | 500W |
| Lumens(lm) | 80000 |
| Other Power Options | 300W/400W/1000W/1200W |
| Weight(kg) | 16.8 |
| Sizes(mm) | 460*490*330 |
| Efficacy | 160lm/W |
| CCT | 2700-6500K |
| CRI | ≥80Ra |
| LED Chips | San'an 5050/Lumileds 5050 |
| PF | >0.95 |
| Input Voltage | AC100-277V(Moso) |
| Beam Angle | 10°/25°/45°/60° |
| Work Temp | -35~55℃ |
| Humidity | 15%~90% RH, no condensing |
| Finish | Sprayed with outdoor special powder |
| Life Span | ≥50,000 Hrs (LM70 @ 35℃ ) |
| IP Grade | IP66 |
| IK Grade | IK08 |
| Body material | PC lens + Aluminum housing |
| Power Wire | Rubber cable(3*1mm²) L=0.3m |
| Electronic safety grade | Class I |
The bracket is equipped with a dial 180° adjustable.
Hollow design of convection heat dissipation;
Stable working performance longer life span.
Moso LED Driver AC100-277V;
Good stability, high efficiency, flicker-free, anti-surge.
Circular lamp body with calculus optical lenses;
More accurate projection azimuth and farther irradiation distance.
High brightness Lumileds SMD5050;
Light efficacy160lm/W, junction temperature <70℃.
