Product Details:
|
| Power: | 600W | Lumen: | 78000lm |
|---|---|---|---|
| Input Voltage(V): | AC100-277V | Warranty(Year): | 5-Year |
| Light Source: | High Brightness LED | Support Dimmer: | Customized |
| Applications: | High Pole Lighting, High Mast Lighting, Tunnel Lighting | LED Chip: | San'an/ Lumileds 3030 |
| CCT: | 2700K-6500K | Service: | DIALux Calculation And Visualization |
| Highlight: | 600w led tunnel light,led high mast light 600w,optical lens led high mast light |
||
Optical Lens Design 600W High Light Mast for Airport Runway
Featuring advanced optical lens design, this 600W high light mast is ideal for airport runway lighting. It provides precise and focused illumination, enhancing safety and visibility for aircraft takeoff and landing. The optical lens technology ensures optimal light distribution and reduces glare for effective runway lighting.
| Model | YXR-TL-600W-G |
| Power | 600W |
| Lumen (lm) | 78000 |
| Weight (kg) | 12.6 |
| Sizes(mm) | 400*620*180 |
| Light Efficiency | 130lm/W |
| CCT | 2800-3000K;3000-3200K;4000-4500K;5000-5500K;6000-6500K |
| CRI | ≥70Ra |
| LED | San'an/Lumileds SMD 3030,120pcs per module |
| PF | >0.97 |
| Input Voltage | AC100-277V(Moso) |
| THD | 15%<THD<20% |
| Beam Angle | 30/60°/90°/70*140° |
| Work Temp | -35~+55℃ |
| Humidity | 15%~90%RH,no condensing |
| Finish | Sprayed with outdoor special powder |
| Life Span | ≥50,000 Hrs (LM80@35℃) |
| IP Grade | IP66 |
| IK Grade | IK08 |
| Body material | PC lens + Aluminum housing |
| Power Wire | Rubber cable(3*1mm²) L=0.3m |
| Electronic safety grade | Class I |
IP66 Waterproof
Equipped with silicone waterproof ring, integrated waterproof lens. lP66 waterproof and dust-proof no fear of
harsh environment.
Gear scale design
It is more convenient to adjust and fix the angle and at the same time.avoid the phenomenon of paint peeling
due to friction between the bracket and the lamp body.
High -quality rotation screw
304 stainless steel screws, long -term durability, anti-rust and anti -corrosion.
Acrylic optical lens high brightness LED Chips
Acrylic optical lens effectively casts the light around, making the light shine farther and brighter.
Moso LED driver
Famous brand Moso or other brand driver optional, good stability, high efficiency, flicker free, anti-surge.
Die-casting module radiator
The die-casting process module radiator is adopted the bottom plate is in close contact with the light source
and the air convection air duct ensures stable heat dissipation performance.
FAQ
Q1: Are you a manufacturer ?
USHINERAY: Yes, we have our own factory with over 14 years R&D and manufacture experience base on ISO quality management since 2009.
Q2. Can I have a sample order for LED Stadium Light?
USHINERAY: Yes, sample order is always welcomed.
Q3. How about the lead time of LED Stadium Light ?
USHINERAY: 5-7 days for sample order, 10-20 days for mass production order base on order quantities.
Q4: How do you ship the finished production ?
USHINERAY: By SEA, AIR or Express(DHL,UPS,Fedex,TNT,etc) are optional.
Q5: Is it OK to print my logo on LED Stadium Light ?
USHINERAY: Yes, we offer screen printing or laser printing
Q6: How to proceed an order for LED Stadium Light ?
USHINERAY: Firstly, send your detail requirement and application environment, secondly we will recommend some suitable products and solutions to you according to your request. Thirdly, after confirm all the details, you can issue the purchase order and make the payment , then we start for the production and arrange the shipment.
Q7: How to deal with the defective?
USHINERAY: All of our product are produced in strict quality control system, the defective rate is less than 0.2% according to our shipment records. We offer 5 years warranty, if there is any defective during the warranty, please provide the picture or video, we will ship the new lights to you within a few days or send it together with your next order.
